PV400 (VBW9) Fan 2.2Kw

Name: PV400 (VBW9) Fan 2.2Kw
Brand: Agricultural Supply Services
Price: 823.00 GBP
Availability: InStock

Please call us on 01452 741112 to enquire

PV400 Fan, 2.2kw, for crop conditioning via Pedestal or Underflow Ventilation. Class leading output and superb longevity.

2.2kw, 3ph fan

Designed for large air movement across a range of back pressures
5 year warranty
One fan for 400 tonnes of stored crop, use with Maxi Pedestals
Made in Britain – Proven in grain stores for over 40 years

The PV400 is an exhausting fan only with massive back pressure characteristics. The crop conditioning fan is all steel construction with integrally fitted guards and a 200mm round inlet spigot.

PV400 Fans need to be wired in by a qualified electrician (no plug supplied). PV400 Fans can be purchased with a Multi Fan Hub or Grain Fan Assist Wireless.

No starter/overload included – available.

Specifications

PV400 Fans need to be wired in by a qualified electrician. PV400 Fans can be purchased with a Multi Fan Hub or Grain Fan Assist Wireless. Starter/overload are available (not included).

PV400 – 2.2kw, 3ph fans

Designed for large air movement across a range of back pressures

All steel construction

Integrally fitted guards with 200mm round inlet spigot

3 year manufacuring defect warranty

Use with Maxi Pedestals

How many fans do I need?

MOISTURE CONTENT OF CROP	TONNES OF GRAIN VENTILATED BY A PV250 OR EVOLUTION FAN	TONNES OF GRAIN VENTILATED BY A PV400 FAN
15% and below	250	400
16-17%	175	300
18%	100	200
